USB: USB 2.0 Full speed , USB 1.1 compatible Power consumption: USB side - up to 100mA
Transceiver side up to 100mA at 13.8V (max. 16V) Radio Port: RXD, TXD max.
56K Baud
- levels: TTL, inverted TTL, open collector bus, RS232 CW: open collector, max 30V/400mA PTT: open collector, max 30V/400mA
Dimensions: W 103mm (4.05") x H 44mm (1.73") x D 85mm (3.35") Weight: 600g (1.3lbs)
Requirements:
Minimal - PC with
Windows 2000, 128 MB RAM, CD-ROM, USB1.1 port, Transceiver, logger or control software (any) Recommended - PC
with Windows XP or higher, 256MB RAM, CD-ROM, USB2.0 port, Transceiver with
computer port, CW paddle, PS/2 keypad, logger or control software (any)
