Station Master listens to the communication between radio and computer and extracts the necessary frequency information for antenna selection or amplifier band switching.  If the radio is not communicating with computer (computer is OFF or not connected), Station Master will poll the radio to acquire the needed information (capability to be available at the end of August 2008).  With Station Master you will never forget to switch one of many accessories when changing bands!  You'll be on the air with proper antennas, bandpass filters and other accessories before your competition - even if your computer locks up.



Station Master can interface directly to your transceiver, replacing a separate CAT interface and rotor controller or it can connect to a microHAM microKEYER II, or MK2R.   Station Master is the only band decoder that can automatically split an amateur band into as many segments as necessary and automatically control antenna tuning networks and is one of a very few band decoders able to acquire the exact frequency information from Icom transceivers and decode the WARC bands.



Package contains:  Station Master�, miniDIN 6 to miniDIN 6 cable, RCA to RCA cable, coaxial 2.1/5.5mm power plug and CD-ROM containing microHAM USB Device Router and documentation.
